UGREEN 25962 DisplayPort KVM Switch 2 In 1 Out (CM695)

UGREEN CM695 (25962) DisplayPort KVM Switch – Key Specification

• 2 In 1 Out KVM: Control 2 computers with 1 monitor, keyboard, and mouse

• Max Resolution: Up to 8K @ 60Hz (DisplayPort 1.4)

• Backward Support: 4K@120Hz, 1440p, 1080p, etc.

• USB Hub: 3× USB-A + 1× USB-C (USB 3.0, up to 5Gbps)

• Switching Methods: Button + wired desktop controller (no hotkey)

• OS Support: Windows, macOS, Linux (plug & play)

• Input Ports:

  • 2 × DisplayPort 1.4 (HDCP 2.3)

• Output Port:

  • 1 × DisplayPort 1.4

• Video Bandwidth: 32.4 Gbps total

• Color Formats: RGB, YCbCr 4:4:4 / 4:2:2 / 4:2:0

• Color Depth: 8 / 10 / 12-bit

• HDR / 3D / CEC: Supported

• USB Ports:

  • 3 × USB-A (USB 3.0)

  • 1 × USB-C (USB 3.0)

• Transfer Speed: Up to 5Gbps

• Total Current Output: Up to 3A (shared)

• Extra Port: Mini USB (for controller)

• Power Input: USB-C (5V / 4A recommended)

• Switch Memory: Remembers last selected PC after restart

• Audio Support: LPCM (minimal delay)

• Protection: Overcurrent & short-circuit protection

• Material: Aluminum alloy

• Weight: ~498g

• Operating Temp: 0°C – 45°C

• Warranty: 1 Year
