BOYA mini-16 Wireless Microphone for ISO Devices

Specifications for the BOYA mini‑16 Wireless Microphone for iOS Devices:

• Model: BOYA mini‑16

• Platform: Designed specifically for iOS (Lightning connector) – also available in USB‑C version for Android/other devices

• Weight: Transmitter just 5 g — one of the smallest and lightest wireless mics

Transmitter (TX)

• Dimensions: 31 × 15 × 16.4 mm

• Weight: 5 g

• Mic: Built‑in 6 mm condenser capsule

• Sample Rate / Bit Depth: 48 kHz / 16‑bit

• Frequency Response: 20 Hz – 20 kHz

• Signal‑to‑Noise Ratio (SNR): > 80 dB

• Max SPL: 120 dB

• Latency: ~25 ms

• Recording Mode: Mono only, no onboard recorder

• Noise Cancellation: 3 adjustable levels via receiver button (weak/medium/strong)

• Voice Changer: 3 modes (deeper, sweeter, original) activated by a double-click

• Battery Life: Up to 6 hours on a single charge

• Transmission Range: Up to ~100 m line‑of‑sight

Receiver (RX)

• Connector Type: Lightning plug (for iOS)

• Power: Draws power directly from the connected device — no separate battery

• Features: Plug‑and‑play; audio routed through device speaker; no gain control or headphone monitoring

• Audio Playback: Supports playback without unplugging

Charging Case

• Capacity: 260 mAh (UC/DI version), sufficient for ~1.5 transmitter charges (~30 hours total use)

• Dimensions / Weight: ~67.4 × 48.4 × 22.5 mm; ~29 g

Operation & Controls

• Noise Cancellation: Cycle levels by single-click on receiver NR button. LED blinks indicate level: 1 blink (weak), 2 (medium), 3 (strong)

• Voice Changer: Double-click same button cycles modes, with LED color blink: first for deeper, second for sweeter, third for original

• Pairing: Long press NR button on receiver to enter pairing mode

What’s in the Box

• 1× Transmitter with built-in mic

• 1× Lightning receiver

• 1× Magnetic charging cable

• 1× Compact charging case

• 1× Carrying pouch

• User manual
